4-18

VENICE Client Software User Guide

y If necessary, configure the input format so that it matches the signal

present at the server’s input with the Input settings items (see sec-

tion “Configuring the Input Settings” on page 4-2).

y Determine a file name and path for the file(s) to be recorded with

the Destination items as described in section “Selecting the Stor-

age Location and File Name” on page 4-5.

y If necessary, specify the essences that you want to record with the

Input select items (see section “Selecting Essences for Record” on

page 4-3).

y If necessary, set up the file format(s) of the file(s) to be recorded via

the Output settings items (see section “Configuring the Output

Settings (File Settings)” on page 4-4).

y Then activate the button SLAVE (see section “Slave Mode” on

page 2-9).

The slave mode control window will be displayed on the screen. After

this the VENICE server waits for a record command via RS-422 to begin

a capturing of the signal present at the input of the VENICE server.

To terminate the slave mode recording perform the following:

y Either send the respective command via RS-422 or terminate the

slave mode by clicking on the CLOSE button of the slave mode

control window.

This stops the capturing process right away.

The player/recorder controls provide no function in a slave re-

cording operation.
